Cost-effective
Low price and high performance with intel quad core CPU.
Centerm D610 Enterprise Thin Client
Centerm D610 Enterprise Thin Client
D610 is a highly efficient and powerful thin client for both local computing and Microsoft, Citrix, VMware virtual desktop environments. It has a zero-client style desktop with TOS or a Windows style desktop with WES&Win10.
FEATURES
-
-
High reliability, No moving parts
MTBF 40,000 hours, fanless cooling.
-
Low power consumption
A green product with low power consumption and low CO2 emission.
-
Multiple interfaces
4 serial port, 1 parallel port, 1 USB 3.0 port, 5 USB 2.0 port, 1 DVI-I port.
-
Multiple VDI protocol supported
Widely supports Citrix ICA/HDX, VMware PCoIP and RDP.
CONNECTIVITY
- 1. Power Button
- 2. USB 2.0 Port
- 3. Mic-in
- 4. Line-out
- 5. USB 3.0 Port6. DC 12V Input
- 7. PS/2 Keyboard
- 8. PS/2 Mouse
- 9. Serial Port
- 10. DVI-I Port
- 11. Parallel Port
- 12. RJ-45
- 13. Kensington Lock Slot
Features
● Cost-effective
Low price and high performance with intel quad core CPU.
● High reliability, No moving parts
MTBF 40,000 hours, fanless cooling.
● Low power consumption
A green product with low power consumption and low CO2 emission.
● Multiple interfaces
4 serial port, 1 parallel port, 1 USB 3.0 port, 5 USB 2.0 port, 1 DVI-I port.
● Multiple VDI protocol supported
Widely supports Citrix ICA/HDX, VMware PCoIP and RDP.
Connectivity
Specification
| Processor | Intel quad core 2.0GHz; |
| Available Operating System | WES7 / WIN 10 IOT / TOS1 |
| Protocol | Citrix Receiver / VMware view / RDP client |
| Management | CDMS2 |
| RAM (DDR3L) | 2GB |
| Storage (SSD) | 8GB |
| Display | DVI-I x 1 (DVI-to-VGA adapter included) |
| Resolution | DVI-I:1920x1200 @ 60Hz (DVI) |
| Color Depth | 32 bits |
| Dual Display | Support |
| LAN | x 1 (10/100/1000 Base-T Fast Ethernet, RJ-45) |
| USB 2.0 | x 5 (1 in front, 4 in rear) |
| USB 3.0 | x 1 |
| Serial Port | x 1 (extensible to 4 via cable) |
| Parallel Port | x 1 |
| PS/2 Port | x 2 |
| Audio | Line-out x 1 , Mic-in x 1 |
| Dimension / Packaging | 206mm x 48mm x 215mm (no stand included)206mm x 83mm x 223mm (stand included) |
| Net Weight | 1.2 kg |
| Adapter | Worldwide auto-sensing 100-240V AC, 50/60 Hz,12V/3A DC |
| Power Consumption | < 15w |
| Stand | Vertical feet standard |
| Security | Standard Kensington anti-theft keyhole |
| Cooling | Fan-less Convection |
| Operation Temperature | 0℃ to 40℃ |
| Relative Humidity | 30% to 90% non-condensing |
| Processor | Intel dual core 2.41GHz |
| RAM (DDR3L) | Available at 8GB |
| Storage | 1 * SATA |
| Display | 1 x DP (1920x1200@60Hz) |
| Network | Additional 1 x (10/100/1000 Base-T Fast Ethernet, RJ-45)1 x Mini-PCIE wireless module |
| Mounting | VESA mounting kit |
SPECIFICATION (standard)
+- Processor
- Available Operating System
- Protocol
- Management
- RAM (DDR3L)
- Storage (SSD)
- Display
- Resolution
- Color Depth
- Dual Display
- LAN
- USB 2.0
- USB 3.0
- Serial Port
- Parallel Port
- PS/2 Port
- Audio
- Dimension / Packaging
- Net Weight
- Adapter
- Power Consumption
- Stand
- Security
- Cooling
- Operation Temperature
- Relative Humidity
- Intel quad core 2.0GHz;
- WES7 / WIN 10 IOT / TOS1
- Citrix Receiver / VMware view / RDP client
- CDMS2
- 2GB
- 8GB
- DVI-I x 1 (DVI-to-VGA adapter included)
- DVI-I: 1920x 1200 @ 60Hz (DVI)
- 32 bits
- Support
- x 1 ( 10/ 100/ 1000 Base-T Fast Ethernet, RJ-45)
- x 5 ( 1 in front, 4 in rear)
- 1
- x 1 (extensible to 4 via cable)
- 1
- 2
- Line-out x 1 , Mic-in x 1
- ” 206mm x 48mm x 215mm (no stand included)
- 206mm x 83mm x 223mm (stand included)”
- 1.2 kg
- “Worldwide auto-sensing 100-240V AC, 50/60 Hz,
- 12V/3A DC”
- < 15w
- Vertical feet standard
- Standard Kensington anti-theft keyhole
- Fan-less Convection
- 0℃ to 40℃
- 30% to 90% non-condensing
SPECIFICATION (optional)
+- Processor
- RAM (DDR3L)
- Storage
- Display
- Network
- Mounting
- Intel dual core 2.41GHz
- Available at 8GB
- 1 * SATA
- 1 x DP ( 1920x 1200@60Hz)
- ” Additional 1 x (10/ 100/ 1000 Base-T Fast Ethernet, RJ-45)
1 x Mini-PCIE wireless module” - VESA mounting kit
